Stirring quantity max. per stirring position (H2O): 40 l
Motor rating input: 168 W
Motor rating output: 131 W
Motor principle: Brushless DC
Speed display: TFT
Speed range: 0/30 - 2000 rpm
Intermittent operation: yes
Viscosity max.: 50000 mPas
Output max. at stirring shaft: 126 W
Permissible ON time: 100 %
Torque max. at stirring shaft: 60 Ncm
Speed adjustment: stepless
Setting accuracy speed: ±1 rpm
Deviation of speed measurement n > 300rpm: ±1 %
Deviation of speed measurement n < 300rpm: ±3 rpm
Stirring element fastening: chuck
Connection for ext. temperature sensor: PT1000
Temperature display: yes
Chuck range diameter: 0.5 - 10 mm
Hollow shaft, inner diameter: 11 mm
Hollow shaft (push-through - when stopped): yes
Fastening on stand: extension arm
Extension arm diameter: 16 mm
Extension arm length: 220 mm
Torque display: yes
Speed control: electronic
Nominal torque: 0.6 Nm
Torque measurement: trend
Deviation of torque measurement I: ±6 Ncm
Timer: yes
Timer display: TFT
Time setting range: 1 - 6000 min
Temperature measuring range: -10 - +350 °C
Temperature measurement resolution: 0.1 K
Accuracy of temperature measurement: ±0.5 + tolerance PT1000 (DIN EN 60751 Class A) K
Limit deviation temperature sensor: ≤ ± (0.15 + 0.002xITI) K
Housing material: alu-cast coating / thermoplastic polymer
Communication distance (depend onbuilding) max.: 150 m
Dimensions (W x H x D): 86 x 267 x 230 mm
Weight: 4.7 kg
Permissible ambient temperature: 5 - 40 °C
Permissible relative humidity: 80 %
Protection class according to DIN EN 60529: IP 40
RS 232 interface: yes
USB interface: Micro-USB
Voltage: 115 V
Frequency: 50/60 Hz
Power input: 176 W
