Stirring quantity max. per stirring position (H2O): 20 l
Motor rating input: 32 W
Motor rating output: 22 W
Motor principle: Brushless DC
Speed display: LCD
Speed range: 0/30 - 500 rpm
Viscosity max.: 20000 mPas
Output max. at stirring shaft: 15.7 W
Permissible ON time: 100 %
Torque max. at stirring shaft: 30 Ncm
Speed adjustment: Turning knob
Setting accuracy speed: ±1 rpm
Deviation of speed measurement n > 300rpm: ±1 %
Deviation of speed measurement n < 300rpm: ±3 rpm
Stirring element fastening: chuck
Connection for ext. temperature sensor: PT1000
Temperature display: yes
Chuck range diameter: 0.5 - 8.2 mm
Hollow shaft, inner diameter: 8.5 mm
Hollow shaft (push-through - when stopped): yes
Fastening on stand: extension arm
Extension arm diameter: 13 mm
Extension arm length: 160 mm
Torque display: yes
Speed control: electronic
Nominal torque: 0.3 Nm
Torque measurement: trend
Deviation of torque measurement I: ±3 Ncm
Timer: yes
Timer display: LCD
Time setting range: 0 - 6000 min
Temperature measuring range: -10 - 350 °C
Temperature measurement resolution: 0.1 K
Accuracy of temperature measurement: ±0.5 + tolerance PT1000 (DIN EN 60751 Class A) K
Limit deviation temperature sensor: ≤ ± (0.15 + 0.002xITI) K
Housing material: alu-cast coating / thermoplastic polymer
Dimensions (W x H x D): 60 x 173 x 136 mm
Weight: 1.26 kg
Permissible ambient temperature: 5 - 40 °C
Permissible relative humidity: 80 %
Protection class according to DIN EN 60529: IP 54
USB interface: Micro-USB
WPAN interface: yes
Voltage: 100 - 240 V
Frequency: 50/60 Hz
Power input: 32 W
DC Voltage: 24 V=
Current consumption: 1300 mA
