Slotted Steel Weights

Slotted Steel Weights

Description

Used for consolidation (oedometers), shear testing machines and other applications.
Manufactured from steel. Protected against corrosion. Accurately calibrated assuring the specified tolerance.

Four weight sets are avaialble, for coverring the majority of the Standard loading sequence:

  • CONSOLIDATION: 64 kg or 80 kg
  • SHEAR: 37.5 kg or 34 kg



Single weight can be ordered separatelty (see accessories)

Label/Normering

Technische specificaties

Technical Specifications

Consolidation test

26-WF0230/C2 - 64 kg
27-WF0270/A - 0.250 kg  2
27-WF0271/A - 0.500 kg1
27-WF0272/A - 1 kg1
27-WF0273/A - 2 kg1
27-WF0274/A - 4 kg1
27-WF0275/A - 8 kg7



Consolidation test

26-WF0230/D2 - 80 kg
27-WF0270/A - 0.250 kg  2
27-WF0271/A - 0.500 kg3
27-WF0272/A - 1 kg1
27-WF0273/A - 2 kg1
27-WF0276/A - 5 kg3
27-WF0277/A - 10 kg6



Shear test

27-WF0230/C3 - 37.5 kg
27-WF0270/A - 0.250 kg  2
27-WF0271/A - 0.500 kg2
27-WF0272/A - 1 kg2
27-WF0273/A - 2 kg3
27-WF0274/A - 4 kg3
27-WF0275/A - 8 kg2



Shear test

27-WF0230/C4 - 34 kg
27-WF0272/A - 1 kg2
27-WF0273/A - 2 kg1
27-WF0277/A - 10 kg3

Order nummers

26-WF0230/C2: Set of slotted steel weights total value 64kg: 2x0.25; 1x0.5; 1x1; 1x2;1x4;7x8kg 26-WF0230/D2: Set of slotted steel weights total value 80kg: 2x0.25kg; 3x0.5kg; 1x1kg; 1x2;3x5kg; 6x10kg

Accessoires & toebehoren



27-WF0270/A: Slotted steel weight 250g 27-WF0271/A: Slotted steel weight 500g 27-WF0272/A: Slotted steel weight 1kg 27-WF0273/A: Slotted steel weight 2kg 27-WF0274/A: Slotted steel weight 4kg27-WF0230/C3: Set of slotted steelweights tot.37.5kg: 2x0.250kg;2x0.500kg; 2x1kg; 3x2kg; 3x4kg; 2x8kg. 27-WF0230/C4: Additional set of slotted steel weights: 2x1kg; 1x2kg; 3x10kg. 27-WF0275/A: Slotted steel weight 8kg 27-WF0276/A: Slotted steel weight 5kg 27-WF0277/A: Slotted steel weight 10kg
