Special Calibration Procedures

Description

These procedures can be applied to Concrete, Cement and Flexural testing machines fitted with WIZARD Auto, PILOT Pro, AUTOMAX Pro and AUTOMAX Multitest testing systems.
The special calibrations are useful to extend the Class 1 load measurement accuracy in the lower part of the scale. It is suggested when other test methods (flexure, indirect tensile) or low strength material testing shall be performed in the compression machine. To be specified at the time of order.


50-C0050/CAL
Special calibration of load digital readout unit assuring class 1 from 1% of testing machine full scale (maximum load). Suitable for:

  • All testers from 1500 to 5000 kN cap.
  • All cement testers 300 and 600 kN cap.
  • All flexural testing frames fitted with load cell



50-C0050/CAL5
Special calibration of load digital readout unit assuring class 1 from 5% of testing machine full scale (maximum load). Suitable for:

  • All cement double chamber frames for 15 kN cap.
  • All flexural testing frames fitted with pressure transducers



50-C0050/1CAL
Special calibration of load digital readout unit assuring class 1 from 0.5 kN.
Available only for 300kN and 500 kN capacity (with load cell) PILOT Pro or AUTOMAX Pro PCS systems.

Label/Normering

  EN 12390-4‰ASTM E74

Technische specificaties

Technical Specifications




Order nummers

50-C0050/CAL: Special calibration of load digital readout unit assuring class 1 from 1% of testing machine full scale (maximum load) 50-C0050/CAL5: Special calibration of load digital readout unit assuring class 1 from 5% of testing machine full scale (maximum load)

Accessoires & toebehoren



: 50-C0050/1CAL:

Special calibration of load digital readout unit assuring class 1 from 0.1% of testing machine fullscale (Class 1 accuracy from 0.5 to 500 kN). Available only for C92P1x machines.
